LDA型电动单梁起重机是在“LD”的基础上进行改进设计的，较“LD型”具有结构合理，整机刚性强的特点。整机与CD，型、MD型电动葫芦配套使用，是一种轻小型的起重机械。共起重量为1t—10t。跨度为7.5—22.5m，工作级别为A3-A5，工作环境温度为-25℃~40℃。

本产品广泛用于工厂、仓库、料场等不同场合品运货物，禁止在易燃、易爆、腐蚀性介质环境中使用。

本产品设有地面和操纵室两种操作形式。操纵室有开式、闭式两种，可根据实际情况分为左成右而安装两种形式，入门方向有侧面及端面两种，以满足用户在各种不同需要的情况下进行选择。

LDA model single beam motor crane is improved and designed on the basis of LD model. It is characterized by more reasonable structure and higher strength steel as awhole. Used together with CD,model, MD,model electric hoist as a complete set, it is light duty crane with a capacity of 1 to 10tons. The spanis 7.5-22.5m. Working gradeis A3-A5. Working temperature is-25℃ to 40℃.

This product is widely used in plants,warehouses,material stocksto lift goods. It is prohibited to use the equipmentin the combustible,explosive or corrosive environment.

This product has two operational methods,ground or operational room which has open model and closed model and can be installedon left or right side according to the practical
